Self-contained Hydrauilc MK5
The MK5 is a reliable self-contained hydraulic actuator, of which more than a million have already been built. The pump, cylinder, valves and reservoir are combined into one, compact, maintenance-free unit.
Every MK5 comes with a pressure relief valve and a flow control valve to ensure smooth descent. The MK5 is easy to install and is built for long life.
Features
- Stroke lengths: multiple possibilities between 80 and 400 mm
- Maximum dynamic push force: 10 kN at 270 bar
- Descent control: flow control valve
- Pressure relief valve: installed
- Single acting cylinder
- Optional: holes on the pedal shaft, mounting brackets, suction tube, different actuator colors, TÜV certified
Benefits
- Reduced total cost of ownership
- Proven high quality, product built for long life
- Compact self contained design
- Quiet and smooth operation
- Maintenance-free
- Ease of installation
- Manual override, hand release option
- “Autoclave” proof
- Operating comfort
