Manual Multi Cylinder (MMC)
The Manual Multi Cylinder (MMC) is a reliable hydraulic system to operate multiple movements within your application. This system enables the user, by means of a selector, to select which cylinder to operate. The selector is integrated in the pump which results in less build-in space and less weight. All available single acting and double acting cylinders can be combined, this gives you the flexibility to create the most suitable system for your application.
Features
- Operate up to 4 cylinders with one foot pump
- 1 – 4 single/double acting hydraulic cylinders: 8,5 and 14 kN push forces
- 2 hoses per cylinder
- Stroke lengths available 60- 400 mm
- The selector and the pump are integrated in one bloc.
- Selector function: by rotating the shaft, one of the cylinders can be selected.
- Pump function: the selected cylinder is extended by pumping the pump foot pedal down.
- The selected cylinder is retracted by moving (by single acting cylinder) or pumping (by double acting cylinder) the pump foot pedal down.
Benefits
- Reduced total cost of ownership
- Proven high quality, product built for long life
- Enhanced performance
- High load forces, optimum technology for bariatric needs
- Suitable for mobile applications
- No power supply needed
- Compact sizing
- Less build-in space
- Less weight
- Flexibility: all available cylinders can be combined
- Functional safety
- System 100% tested and pre-filled
- Valves with integrated safety function mounted to the cylinder
