Hydraulic Latches
The Power-Packer hydraulic latch will satisfy new and existing latch applications. The compact size and strength of the latch makes it ideal for single or multiple latch requirements. Its unique, patented design includes a visual latch indicator pin: pin reaction indicates the latch has engaged mechanically and extension of the pin indicates the latch has disengaged hydraulically.
Power-Packer Hydraulic Latches Features
- SAE #4 straight threads on both hydraulic ports
Furnished with upper catch bracket - Engages mechanically
- Releases hydraulically at 300 psi (20.7 Bar)
- Can be used with or without suspension device
- Indicator pin is retracted when latch is engaged
- Maximum vertical pull load – 10,000 lbs (4536 kg)
- Maximum hydraulic pressure – 5,000 psi (345 Bar)
- Operating pressure to open latch – 200-300 psi (13.8-20.7 Bar)
- Recommended Fluid – MIL-H-5606 or equivalent
- Recommended operating temperature range – (-30°F to 130°F or -34°C to 54°C)
- Corrosion-resistance – 200 hours per B117
- Weight with catch bracket – 6.5 lbs (2.95 kg)
Benefits
- Visual Indicator Pin – Standard
- Electric indicator switch – Optional
- Compact size
- Versatile Mounting
- Corrosion-resistance (200 hours per B117)
